BPS 8 SM 102-10 Bar code positioning system

BPS 8 SM 102-10
A compact bar code positioning system with a laser light source and RS 232 interface.
  • SKU
    2110-50137879
  • Manufacturer code
    50137879
  • Scanning principle
    Other
  • Type of analogy output
    Other
  • Type of electric connection
    Connector M12
  • Type of switching output
    Other
  • Type of switch function
    Other
  • Operation agent-safety class
    Safety class 3
  • Supply voltage
    4.75 - 5.5 V
  • Width sensor
    15 mm
  • Height of sensor
    48 mm
  • Length of sensor
    40.3 mm
  • Setting procedure
    Other
  • Explosion safety category for gas
    None
  • Explosion safety category for dust
    None
  • Construction type housing
    Cuboid
  • Geometrical resolution
    100 mm
  • Laser protection class
    Class 2
  • Type of light
    Laser diode, red light
  • Max. output current
    100 A
  • Measuring principle for optical distance measurement
    Other
  • Interface
    RS-232
  • Degree of protection (IP)
    IP67
  • Voltage type
    DC
    DC
    DC
    DC
  • Ambient temperature
    0 - 40 °C
  • Pre failure notice
    false
  • Material of optical surface
    Glass
  • Housing material
    Other
  • Material of cable sheath
    Other
  • With time function
    false
  • Supply voltage
    4.75 ... 5.5
  • Ambient temperature
    0 ... 40
  • Interface
    RS 232
  • Depth of field (mm)
    80 ... 140
  • Most suitable applications
    Bar code scanning and positioning
  • Manufacturer Leuze

Product attachments

DS_BPS-8-SM-102-10_eng_50137879 (LINK)
