A-K5P-M12-S-G-5M-BK-2-X-A-4-69 Machine safety accessory

A-K5P-M12-S-G-5M-BK-2-X-A-4-69
Pre-wired cable
5-pole
  • SKU
    4030661474366
  • Manufacturer code
    103010816
  • PIM maintenance status
    Discharge "Online catalog"
  • SAP, basic quantity unit
    Piece
  • SAP, EAN (European Article Number)
    4030661474366
  • SAP, product group
    HAWA: Electromechanical switchgear
  • SAP, gross weight
    180.000 g
  • SAP, net weight
    180.000 g
  • Web Type
    Product range
  • Type of Execution, IP Protection class, General
    IP67
    IP65
    IP69
  • Coding, Lead colours
    Color code DIN47100
  • Diameter, Wire cross-section,
    0.34 mm<sup>2</sup>
  • Cable length
    5 m
  • Electrical data, Connector 1, Pin assignment, PIN 1
    Brown
  • Electrical data, Connector 1, Pin assignment, PIN 2
    White
  • Electrical data, Connector 1, Pin assignment, PIN 3
    Blue
  • Electrical data, Connector 1, Pin assignment, PIN 4
    Black
  • Electrical data, Connector 1, Pin assignment, PIN 5
    Grey
  • Material, cable mantle
    PUR
  • Number, cable wires, indication with cable cross-section, electrical
    5
  • Number, cable wires, electrical
    5
  • Temperature, ambient temperature, connector[generated product variant]
    -30 ... +90 °C
  • Temperature, ambient temperature, connector, maximum
    90 °C
  • Temperatur, ambient temperature, connector, minimum
    -30 °C
  • Voltage, rated operating voltage
    60 VDC
  • Voltage, type
    DC
    AC
  • Voltage, rated operating voltage
    60 VAC
  • Coding, Connector, Side A
    A
  • Color, Sheath (electrical)
    Black
  • Colour, Connector, Handle, Side A
    Black
  • Current, Rated operating current
    4000 mA
  • Current, Thermal test current
    4 A
  • Type of Execution, Connector, Bolting device, Side A
    Screw locking
  • Type of Execution, Connector construction form, Side A
    straight
  • Type of Execution, Connector enclosure, Side A
    Female connector, M12
  • Diameter, Cable (electrical)
    5.20 mm
  • Biegeradius, Leitungsinstallation, fest,
    5 x Ø-cable
  • Biegeradius, Leitungsinstallation, bewegt,
    10 x Ø-cable
  • Material, Connector, Gland, Side A
    Metal, CuZn, nickel-plated
  • Material, Connector, Handle, Side A
    Plastic, TPU
  • Temparture, ambient temperature, cable installation, drag chain[generated product variant]
    -25 ... +60 °C
  • Temparture, ambient temperature, cable installation, drag chain, maximum
    60 °C
  • Temparture, ambient temperature, cable installation, drag chain, minimum
    -25 °C
  • Temparture, ambient temperature, cable installation, fixed[generated product variant]
    -50 ... +90 °C
  • Temperature, ambient temperature, cable installation, fixed, maximum
    90 °C
  • Temparture, ambient temperature, cable installation, fixed, minimum
    -50 °C
  • Temparture, ambient temperature, cable installation, flexible[generated product variant]
    -30 ... +90 °C
  • Temparture, ambient temperature, cable installation, flexible, maximum
    90 °C
  • Temparture, ambient temperature, cable installation, flexible, minimum
    -30 °C
  • Tightening torque, maximum
    1 Nm
  • Voltage, rated operating voltage
    60 V
  • Selection (Yes/No), Trailing-chain-compatible
    Yes (1)
  • Selection (Yes/No), halogen-free
    Yes (1)
  • Standard, standards
    EN IEC 61076-2-101
