L300-M41M12B8-MLM24-UCA Safety locking device

L300-M41M12B8-MLM24-UCA
The L300 is a safety locking device with guard interlocking, designed according to EN ISO 14119 (type 4). It features an open circuit current principle where the actuator is locked when the electromagnet is activated. Safety outputs are active when the safety door is closed and locked.
  • SKU
    2110-50137340
  • Manufacturer code
    50137340
  • With status indication
    false
  • Suitable for safety functions
    true
  • Guard locking force
    9750 N
  • With escape release
    false
  • Type of guard locking
    Quiescent current principle
  • With auxiliary release
    false
  • Rated control supply voltage magnet drive DC
    24 - 24 V
  • Switching principle
    Other
  • Construction type housing
    Cuboid
  • Housing material
    Metal
    Metal
    Metal
    Metal
  • Coating housing
    Powder coating
  • Type of interface
    None
  • Type of interface for safety communication
    None
  • Type of electric connection
    Connector M12
  • Explosion safety category for gas
    None
  • Explosion safety category for dust
    None
  • Ambient temperature during operating
    -20 - 50 °C
  • Degree of protection (IP)
    IP67
  • Most suitable applications
    Ensuring machinery safety by locking safety doors
  • Series
    L300
  • Operational controls
    Standard
  • Encoding level
    High, EN ISO 14119
  • Clamping force, maximum
    9750
  • Performance Level (PL)
    Up to and including e
  • ISO Standard
    EN ISO 13849-1
  • Operating principle
    Open circuit current principle – Actuator locked if electromagnet is activated
  • Manufacturer Leuze

Product attachments

DS_L300-M41M12B8-MLM24-UCA_eng_50137340 (LINK)
