Compact safety laser scanner with a 270° scanning angle, suitable for monitoring areas and ensuring safety with adjustable resolution and multiple protective functions.

SKU

2110-53800233
Manufacturer code

53800233
Scanning interval

0.09 Hz
Number of safety fields

2
Number of protected semiconductor outputs

4
Type of switching output of the OSSD

PNP
Type of electric connection

Cable
Operation agent-safety class

Safety class 3
Width sensor

140 mm
Height of sensor

149 mm
Length of sensor

140 mm
With configurable message output

true
Laser protection class

Class 1
Ambient temperature

0 - 50 °C
Response time

80 s
Transmission range of the safety field

0 m
Transmission range of the alert field

0 m
Switching voltage of OSSD at state "high"

20.8 V
Type of safety according to IEC 61496-1

3
Voltage type

DC
DC
DC
DC
With monitoring function downstream switching devices

false
With alert field output

false
Wavelength of the sensor

905 nm
With restart blockage

false
Suitable for safety functions

false
Most suitable applications

Area monitoring Safety enforcement in industrial settings
Supplyoltage (V)

24
Resolution of protective field (adjustable) (mm)

30
40
50
60
70
150
Performance Level (PL)

d
ISO Standard

EN ISO 13849-1
Connection 1

29 -wire
Connection 2

M12, 4 -pin
Sheathing material

PVC
Operating range (m)

0 ... 3
Cable length (m)

5
