ML-CA40P-9X3-CWW-H1141 LED Machine Light, Mountable cube light

LED Machine Light, Mountable cube light, Operating voltage 18…30 VDC, Cube, Front mounting, Housing material, die-cast aluminium, Weight 200 g, Resistant to coolants and lubricants, Protection class IP67, Operating temperature: -40…+50° C, Number of LEDs: 3, Diffuse illumination, Light color, cool white, Color temperature approx. 6300 K, Illuminance at 1 m approx. 108 lx, Beam angle: 120°, Service life: > 50,000 operating hours, LED protection through integrated thermal management, Operating voltage: 24 VDC, Current consumption: 150 mA at 24 V, Power consumption: 4 W, M12 x 1 connector, Pin assignment: 3 = 0V, 4 = +24V, Direct connection to PLC output
