BI4-M12-LIU Inductive Sensor, With Analog Output

BI4-M12-LIU

Inductive Sensor, With Analog Output, Operating voltage 15…30 VDC, Measuring range 0.5 mm - 3 mm, Flush, Cable length 2 m, M12 × 1 threaded barrel, Chrome-plated brass, 4‐wire, 15…30 VDC, Analog output, 0…10 V and 0…20 mA, Cable connection

  • SKU
    4047101072136
  • Manufacturer code
    1535532
  • Operating voltage
    15 - 30 V
  • Supply voltage
    15 - 30 V
  • Limiting frequency
    200 Hz
  • Relative linearity deflection
    5 %
  • Measuring range
    0.5 - 3 mm
  • Type of electric connection
    Cable
  • Type of analogy output
    0 V ... 10 V
  • Mechanical mounting condition for sensor
    Concise
  • Housing material
    Other
  • Material active area of sensor
    Plastic
  • Material of cable sheath
    Polyvinyl chloride (PVC)
  • Construction type housing
    Cylinder, screw-thread
  • Length of sensor
    64 mm
  • Diameter sensor
    12 mm
  • Ambient temperature
    -25 - 70 °C
  • Degree of protection (IP)
    IP67
  • Flush / Non-flush
    Flush
  • Cable length (m)
    2
  • Manufacturer Turck

Product attachments

file-52391-04c0255791d2ad107f73a4562b3d435b.pdf (PDF, 422.3 kB)
