QMT42VP6FF750Q Photoelectric Sensor, Diffuse Mode Sensor with Fixed-Field Background Suppressio

QMT42VP6FF750Q

Photoelectric Sensor, Diffuse Mode Sensor with Fixed-Field Background Suppression, Operating voltage 10…30 VDC, Max. range 750 mm, Male M12 × 1, 4-pin, Metal housing, ZN, black, Protection class IP67, Operating voltage 10…30 VDC, PNP switching output, Light/dark operation

  • SKU
    0662488573713
  • Manufacturer code
    3057371
  • Type of electric connection
    Connector M12
  • Type of switching output
    PNP
  • Type of switch function
    Change-over contact (NO/NC)
  • Construction type housing
    Cuboid
  • Width sensor
    18 mm
  • Height of sensor
    76.2 mm
  • Length of sensor
    42 mm
  • Sensing mode
    Light-/dark switching
  • Material of optical surface
    Plastic
  • Ambient temperature
    -20 - 55 °C
  • Response time
    1 s
  • Switching frequency
    500 Hz
  • Wavelength of the sensor
    880 nm
  • Type of light
    Infrared light
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Material of cable sheath
    Polyvinyl chloride (PVC)
  • Rated switching distance
    750 mm
  • Max. switching distance
    750 mm
  • Adjustment range
    50 - 750 mm
  • Housing material
    Metal
  • Type of switching output
    PNP
  • Connector gender
    male

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-48918-389741ab376e6dba77ca72c1008aaf0f.pdf (PDF, 524.38 kB)
