BC20-K40WDTC-VP4X2/S930 Capacitive Sensor, For the Food Industry

BC20-K40WDTC-VP4X2/S930

Capacitive Sensor, For the Food Industry, Rated switching distance 30 mm, Flush, 2 cable entries (axial, radial), Plastic LV-30H FWA, Smooth barrel, Ø 40 mm, High protection class IP69K, for harsh environments, Special double-lip seal, Protection against all common acid and alkaline cleaning agents, Laser engraved label, permanently legible, For the food industry, Fine adjustment via potentiometer, DC 4-wire, 10…65 VDC, Complementary contact, PNP output, Terminal chamber

  • SKU
    4047101259896
  • Manufacturer code
    2510105
  • Length of sensor
    91 mm
  • Diameter sensor
    40 mm
  • Flush / Non-flush
    Concise
  • Switching distance
    30 mm
  • Type of switch function
    Change-over contact
  • Type of switching output
    PNP
  • Type of electric connection
    Clamp
  • Type of actuation
    Metallic Target
  • Type of interface for safety communication
    None
  • Construction type housing
    Cylinder plain
  • Supply voltage
    65 - 65 V
  • Voltage type
    DC
  • Switching frequency
    100 Hz
  • Type of interface
    Other
  • Type of switching output
    PNP
  • Rated control supply voltage Us at DC
    65 - 65
  • Flush / Non-flush
    Flush
  • Housing material
    Plastic
  • Manufacturer Turck

Product attachments

file-49644-fdc49ce991bba7b37fe420ead1dbace8.pdf (PDF, 422.95 kB)
