NI5U-Q10S-AP6X Inductive Sensor, With Extended Switching Distance

NI5U-Q10S-AP6X

Inductive Sensor, With Extended Switching Distance, Operating voltage 10…30 VDC, Rated switching distance 5 mm, Non-flush, Cable length 2 m, Rectangular, height 10.2 mm, Active face, lateral, Cable outlet to all sides, Plastic, PP-GF20, Factor 1 for all metals, Increased switching distance, Protection class IP68, Resistant to magnetic fields, Auto-compensation protects against pre-damping, Flush mounted installation on up to 4 sides, DC 3-wire, 10…30 VDC, NO contact, PNP output, Cable connection

  • SKU
    4047101001006
  • Manufacturer code
    1609364
  • Length of sensor
    27.8 mm
  • Flush / Non-flush
    Not flat
  • Switching distance
    5 mm
  • Suitable for safety functions
    false
  • Type of switch function
    Normally open contact
  • Type of switching output
    PNP
  • Type of electric connection
    Cable
  • Type of actuation
    Metallic Target
  • Construction type housing
    Cuboid
  • Supply voltage
    10 - 30 V
  • Voltage type
    DC
  • Switching frequency
    1000 Hz
  • Compression-resistant
    false
  • Width sensor
    16 mm
  • Height of sensor
    10.2 mm
  • Housing material
    Plastic
  • Type of switching output
    PNP
  • Flush / Non-flush
    Non-flush
  • Cable length (m)
    2
  • Manufacturer Turck

Product attachments

file-46288-a19a682de735c90f8a7e8ac2a50ff783.pdf (PDF, 305.8 kB)
