BI10-G30-Y2X 7M Inductive Sensor

BI10-G30-Y2X 7M

Inductive Sensor, Rated switching distance 10 mm, Flush, Cable length 7 m, Threaded barrel, M30 x 1.5, Chrome-plated brass, DC 2-wire, nom. 8.2 VDC, Output acc. to DIN EN 60947-5-6 (NAMUR), Cable connection, ATEX category I M1, mining

  • SKU
    4047101064360
  • Manufacturer code
    1060601
  • Length of sensor
    44 mm
  • Diameter sensor
    30 mm
  • Flush / Non-flush
    Concise
  • Switching distance
    10 mm
  • Type of switching output
    NAMUR
  • Type of electric connection
    Cable
  • Type of actuation
    Metallic Target
  • Construction type housing
    Cylinder, screw-thread
  • Coating housing
    Chromium-plated
  • SIL according to IEC 61508
    None
  • Performance level according to EN ISO 13849-1
    None
  • Voltage type
    DC
  • Switching frequency
    500 Hz
  • Compression-resistant
    false
  • Explosion safety category for gas
    Other
  • Explosion safety category for dust
    Other
  • Housing material
    Metal
  • Flush / Non-flush
    Flush
  • Cable length (m)
    7
  • Manufacturer Turck

Product attachments

file-53593-ec8dbda7fae7a786ecf841da0d2d92e3.pdf (PDF, 502.76 kB)
