L300-B1-M31M23B19-SLM24-UCA Safety locking device

L300-B1-M31M23B19-SLM24-UCA
The L300-B1 is a safety locking device with guard interlocking, featuring a quiescent current principle and high encoding level, designed for secure operational control.
  • SKU
    2110-50142117
  • Manufacturer code
    50142117
  • With status indication
    false
  • Suitable for safety functions
    true
  • Guard locking force
    9750 N
  • With escape release
    false
  • Type of guard locking
    Quiescent current principle
  • With auxiliary release
    false
  • Rated control supply voltage magnet drive DC
    24 - 24 V
  • Switching principle
    Other
  • Construction type housing
    Cuboid
  • Housing material
    Metal
    Metal
    Metal
    Metal
  • Coating housing
    Powder coating
  • Type of interface
    None
  • Type of interface for safety communication
    None
  • Type of electric connection
    Plug-in connection others
  • Explosion safety category for gas
    None
  • Explosion safety category for dust
    None
  • Ambient temperature during operating
    -20 - 50 °C
  • Degree of protection (IP)
    IP65
  • Most suitable applications
    Guard interlocking in compliance with EN ISO 14119 Safety systems requiring high performance levels
  • Series
    L300-B1
  • Operational controls
    2 command devices
  • Encoding level
    High, EN ISO 14119
  • Release device
    Auxiliary release
  • Clamping force, maximum
    9750
  • Performance Level (PL)
    Up to and including e
  • ISO Standard
    EN ISO 13849-1
  • Operating principle
    Quiescent current principle – Actuator locked if electromagnet is deactivated
  • Manufacturer Leuze

Product attachments

DS_L300-B1-M31M23B19-SLM24-UCA_eng_50142117 (LINK)
