FWS 1206 C Machine safety relay module

FWS 1206 C
Detects standstill using 1 or 2 impulse sensors
Uses additional standstill signal, e.g. PLC as second input channel
2 safety contacts
2 Signalling outputs
  • SKU
    4030661297200
  • Manufacturer code
    101170058
  • Current, Switching capacity, Relay, (Auxiliary contacts), maximum
    2 A
  • Current, Switching capacity, Safe relay outputs, maximum
    8 A
  • Current, Switching capacity, Safe relay outputs, minimum
    10 mA
  • Current, Thermal test current
    6 A
  • Current, Utilisation category AC-15, Safe relay outputs
    3 A
  • Current, Utilisation category DC-13, Safe relay outputs
    2 A
  • Type of Execution, IP Protection class, Clearance
    IP54
  • Type of Execution, IP Protection class, General
    IP40
  • Type of Execution, IP Protection class, clips or terminals
    IP20
  • Type of Execution, Mechanical life, minimum,
    20000000 Operations
  • Type of execution, mounting
    Snaps onto standard DIN rail to EN 60715
  • Type of Execution, Overvoltage category IEC/EN 60664-1
    II
  • Depth, General
    121 mm
  • Height, General
    100 mm
  • Width, General
    22.5 mm
  • Electrical data, Cable section, maximum
    2.5 mm²
  • Electrical data, Conduction resistance, maximum
    40 Ω
  • Electrical data, Contact resistance, maximum
    0.1 Ω
  • Material, contacts, electrical
    Ag-Ni 10 and 0.2 µm gold-plated
  • Housing material
    Glass-fibre reinforced thermoplastic, ventilated
  • Standard, standards
    EN IEC 60947-5-1
    EN ISO 13849-1
    EN IEC 60204-1
    EN IEC 60947-5-3
    BG-GS-ET-20
    EN IEC 62061
    EN IEC 60947-5-5
    EN IEC 60947-1
  • Note, contact resistance
    in new state
  • Note, General
    Inductive loads (e.g. contactors, relays, etc.) are to be su
  • Note, applications
    safe standstill monitoring
  • Note, Wiring diagram
    If only one inductive proximity switch is connected to the s
  • Number, LED's
    1
  • Number, Safety contacts
    2
  • PIM maintenance status
    Discharge "Online catalog"
  • PNV, standard, certificates
    cULus
    BG
  • Type of electric connection
    Screw terminals M20 x 1.5
    rigid or flexible
  • Review, Resistance to vibrations to EN 60068-2-6
    10 ... 55 Hz, Amplitude 0.35 mm
  • Review, restistance to shock
    30 g / 11 ms
  • Safety parameter
    EN IEC 61508
  • Safety parameters, Stop-Category
    0
  • SAP, basic quantity unit
    Piece
  • SAP, EAN (European Article Number)
    4030661297200
  • SAP, product group
    Initial
  • SAP, gross weight
    200.000 g
  • SAP, net weight
    200.000 g
  • Temperature, Ambient temperature[generated product variant]
    +0 ... +55 °C
  • Temperature, ambient temperature, maximum
    55 °C
  • Temperature, ambient temperature, minimum
    0 °C
  • Temperature, storage and transport temperature,[generated product variant]
    -25 ... +70 °C
  • Temperature, storage and transport temperature, maximum
    70 °C
  • Temperature, storage and transport temperature, minimum
    -25 °C
  • Voltage, Rated control voltage at AC 50 Hz, maximum
    26.4 VAC
  • Voltage, Rated control voltage at AC 50 Hz, minimum
    20.4 VAC
  • Voltage, Rated control voltage at AC 60 Hz, maximum
    26.4 VAC
  • Voltage, Rated control voltage at AC 60 Hz, minimum
    20.4 VAC
  • Voltage, Rated impulse withstand voltage
    4.8 kV
  • Voltage, rated operating voltage
    24 VDC ± 15 %
  • Voltage, Switching capacity, Relay (auxiliary contacts), maximum
    24 VDC
  • Voltage, Switching capacity, Safe relay outputs, maximum
    250 VAC
  • Voltage, Switching capacity, Safe relay outputs, minimum
    10 VDC
  • Voltage, type
    DC
  • Voltage, Utilisation category AC-15, Safe relay outputs
    230 VAC
  • Voltage, Utilisation category DC-13, Safe relay outputs
    24 VDC
  • Web Type
    Product range
  • Selection (Yes/No), Integral System Diagnostics, status
    Yes
  • Selection, (Yes/No), Wire breakage detection
    Yes
  • Type of application, Terminal designation
    IEC/EN 60947-1
  • Standard, climatic stress
    EN 60068-2-3
    BG-GS-ET-14
  • Tightening torque, torque, clips
    0.6 Nm
  • Tolerance, operating voltage, DC, maximum
    15 %
  • Tolerance, operating voltage, DC, minimum
    -15 %
  • Voltage, Rated control voltage at DC, maximum
    28.8 VDC
  • Voltage, Rated control voltage at DC, minimum
    20.4 VDC
  • Voltage, rated operating voltage
    24 VDC
  • Electrical data, Input signal, HIGH Signal "1"
    10 … 30 VDC
  • Electrical data, Input signal, LOW Signal "0"
    0 … 2 VDC
  • Electrical data, Input resistance at GND
    4000 Ω
  • Hinweis, Delivery capacity
    Phased-out product
  • Note, ISD, Fault
    Failure of the safety relay to pull-in or drop-out
    Fault on the input circuits or the relay control circuits of
    Interruption of the connections to the inductive proximity s
    Failure of the proximity switches
    Failure of one channel being evaluated
  • Note, ISD, General, Fehler
    The following faults are registered by the safety monitoring
  • Web, Delivery notice (date until)
    2023-12-31
  • Selection (Yes/No), Earth connection detection
    Yes
  • Selection (Yes/No), Feedback circuit
    Yes
  • Electrical data, Cable section, minimum
    0.2 mm²
  • Type of Execution, Degree of pollution VDE 0110
    3
  • Number, Signalling outputs
    2
  • Power, electrical consumption, maximum
    5 W
  • Safety parameters, Category, EN ISO 13849
    3
  • Safety parameters, Mission time
    20 Year(s)
  • Safety parameters, Performance Level,
    d
  • Safety values, PFD value
    0.0000001 /h
  • Number, semi-conductor outputs with signalling function, undelayed
    2
  • Selection (Yes/No), Reset with edge detection
    Yes
  • Safety parameters, Safety Integrity Level (SIL)
    2
